FLAGLER 16 ga HEAVY DUTY PITTSBURGH

NEW "FLAGLER" 16 Ga. HEAVY DUTY PITTSBURGH
CAPACITY 16-20 Ga. (MILD STEEL)
DEPTH OF POCKET 1/2". USES APPROX. 1-1/2" OF MATERIAL
EXTENDED SHAFTS FOR 1 SET OF AUX. ROLLS
SPEED 45 FPM (APPROX.)
MOTOR 3 HP /230-460/3/60/ 1,800 RPM
DRIVE DOUBLE V BELT
BASE ARC WELDED STEEL. HEAVY TOP PLATE
DIMENSIONS 56" x 24" x 41"
FEED TABLE HEIGHT 34-5/8"
WEIGHT 720 LBS. (APPROX.)

OPTIONAL: Auxiliary Tooling Available
1/2" Double Seam Rolls
3/8" Double Seam Rolls
7/16" Right Angle Flange Rolls
3/4" Standing Seam Rolls
5/16" Pittsburgh Rolls
5/8" Tap-In (3 in 1) Rolls
5/8" End Cap Rolls
1/2" Tap-In (3 in 1) Rolls
1-1/8" Drive Cleat Rolls
1 1/8" Drive Cleat Rolls with Slitter
1/2" x 180° Hem Rolls
1/2" Male Button Lock Rolls

COMPLETE WITH HARDENED FEED GAUGE, 3 PIECE ROLL/SHAFT/GEAR CONSTRUCTION & CALIBRATED DIAL FOR 16-20ga. MILD STEEL.
