| Weight | 200 LBS. (APPROX.) | 200 LBS. (APPROX.) |
NEW "FLAGLER" 22ga PORTABLE PITTSBURGH
CAPACITY 22ga AND LIGHTER
DEPTH OF POCKETS 5/16". USES APPROX. 1" OF MATERIAL
EXTENDED SHAFTS FOR 1 SET OF AUX. TOOLING
SPEED 17 FPM (APPROX.)
MOTOR 1/2 HP /115/1/60/ 1,800 RPM
DRIVE V BELT
BASE ARC WELDED STEEL
DIMENSIONS 34" x 16" x 14"
WEIGHT 200 LBS. (APPROX.)
OPTIONAL:
FLANGE FOLLOWING ATTACHEMENT
FLOOR STAND WITH DRAWER
AUXILIARY TOOLING AVAILABLE:
3/8" DOUBLE SEAM ROLLS
1-1/8" DRIVE CLEAT ROLLS
3/8" RIGHT ANGLE FLANGE
1/4" x 180° CLOSED HEM ROLLS (26 Ga.)
