NEW "GMC" HYDRAULIC METAL CUTTING SHEAR
MODEL HS-0410MD
CAPACITY 52" x 10 GAUGE (MILD STEEL)
CAPACITY 52" x 14 GAUGE (STAINLESS STEEL)
MAX. CUTTING LENGTH 52"
BLADE RAKE ANGLE 1.5°
26" REAR OPERATED MANUAL BACKGAUGE
THROAT DEPTH 16"
WORKTABLE HEIGHT 30-1/2"
SPRING HOLDDOWN
OIL TANK CAPACITY 15 GALLONS
STROKES PER MINUTE 16-20
MAIN MOTOR 5.5 HP/ 220-440 / 3 / 60
DIMENSIONS: 68" x 36" 55"
WEIGHT 3,100 LBS. (APPROX.)
EQUIPPED WITH:
60" SQUARING ARM
(2) 24" FRONT SUPPORT ARMS
WORK LIGHT
FINGER GUARD
REMOTE FOOT PEDAL
OPTIONAL EQUIPMENT:
-SAFETY FENCE FOR ENCLOSURE OF THE BACK SIDE OF THE MACHINE
-SPECIAL BLADE SET FOR STAINLESS STEEL
