NEW FLAGLER H-2-1/2-7

NEW "FLAGLER" ROLLFORMER MACHINE
MODEL H-2-1/2-7
THIS MACHINE IS STANDARD EQUIPPED WITH NO TOOLING IN THE CENTER POSITION
THERE ARE (2) SETS OF EXTENDED SHAFTS TO FORM ANY OF THE AUXILIARY ROLLS SHOWN BELOW
7 STATIONS
SPEED 30 - 100 FPM (APPROX.)
MOTOR 2 HP /230-460/3/60/ 1,800 R.P.M.
DRIVE MATCHED DOUBLE V BELT
BASE ARC WELDED STEEL. HEAVY TOP PLATE
DIMENSIONS 56" x 24" x 41"
FEED TABLE HEIGHT 34-5/8"
WEIGHT 500 LBS. (APPROX.)
