NEW TOSHIBA TUE-200S
Overview
Description
Workpieces made of various kinds of material can be machined using the TUE-200(S) Vertical Boring & Turning Mill. The TUE-200(S) Vertical Boring & Turning Mill can be machined on the wall-type column with its high rigidity and wide table speed.
Specifications
| Table Dia | 78.74" | 2,000 mm |
|---|---|---|
| Swing | 94.49" | 2,400 mm |
| Work Ht-U/R | 67.72" | 1,720.1 mm |
| Power | 45 hp | 33.6 kW |
| RPM | 240 RPM | 240 RPM |
Specifications (subject to buyer verification):
Swing/Cut inch (mm): 94.5 (2,400)
Cut Height inch (mm): 61 (1,550)
X Stroke inch (mm): -1.97 ~ 53.1 (-50 ~ 1,350)
ARM/Crossrail Vertical Travel (Not NC Axis): 39.3 (1,000)
Z Stroke inch (mm): 35.4 (900)
Table size inch (mm): 78.7 (2,000)
Max. load lbs (kg): 33,000 (15,000)
Table RPM: 240
Live Spindle RPM: 3,000
ATC Tool Pod: 18
Control: FANUC 0i-TF
