USED 2022 ABB IRB 1300-7/1.4

6-Axis Articulated Industrial Robot

Request a Quote
Add to Cart
Payload: 7 Kg
Reach: 1400 mm
Repeatability: +/-0.02 mm
Robot Footprint: 220 x 220 mm
Mounting: Any Angle
Control: OmniCore C30/C90XT
Axis 1: +/-180° @230°
Axis 2: +130°/-90° @116°
Axis 3: +70°/-238° @138°
Axis 4: +/-175° @500°
Axis 5: +/-120° @415°
Axis 6: +/-400° @687°
Max TCP Speed: 6.2 m/s
Arm Load: 0.5 Kg
Applications: Material Handling / Machine Tending / Polishing / Assembly
Note: (5) Units Available - (2) Yr 2022 (1) Yr 2023 (1) Yr 2021
