#106325 Kluge 14 x 22 EHD Die Cutter and Foil Press

#106325 Kluge 14 x 22 EHD Die Cutter and Foil Press

The Kluge EHD 14" x 22" is a platen press designed for foil stamping, embossing, and die cutting, often called "the workhorse of the industry" for its reliability and versatility. Factory reconditioned in 2017.

Platen Size: 14" x 22"
Minimum Sheet Size: 4" x 5"
Maximum Sheet Size: 17" x 24.75"
Magazine Capacity: 14"
Delivery Capacity: 14"
Stock range: Onion skin to .200" board
Inside chase dimensions: 14" x 22"
Outside chase dimensions: 16.25" x 23.5"
Main & back shaft diameter: 4.375"
Maximum operating speed: 3,300 impression per hour (iph)
Air requirement: 90 psi @ 10cfm
Power requirement: 3HP, A.C. 230/460 volt, 3 phase, 1800 rpm, 60 cycle
Machine dimensions: 74" x 50" x 68"
Net weight: ~ 4,400lbs
