Daewoo Lynx 200B CNC Lathe
| Swing | 18.11" | 459.99 mm |
| Machining Length | 11.8" | 299.72 mm |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity | 2" | 50.8 mm |
| Power | 15 hp | 11.2 kW |
| Max RPM | 4,500 RPM | 4,500 RPM |
| Turning Dia | 10.2" | 259.08 mm |
Max. Turning Diameter: 11"
Max. Turning Length: 11.8"
Distance Between Centers: 20"
Max. Bar Capacity: 1.75"
Swing Over Bed: 18"
Chuck: 8" 3-Jaw
Spindle Nose: A2-5
Spindle Speed: 35 - 5000 RPM
Spindle Motor: 15 HP
Number of Turret Stations: 12
X-Axis Travel: 6.3"
Z-Axis Travel: 13"
Rapid Traverse (X-Axis): 787 IPM
Rapid Traverse (Z-Axis): 945 IPM
Fanuc 21-T Series CNC Control
Rigid Tapping
B-208 Kitagawa Hydraulic Chuck
Tool Presetter
Parts Catcher
RS-232
Coolant System
Turbo Chip Conveyor
Foot Switch
Additional Steel Chuck Jaws
