Tennsmith’s slip rolls combine precision-turned, ground and polished high carbon steel rolls with heavy-duty, cast iron end frames and a welded steel base to make an accurate and durable forming tool.
Product description
TENNSMITH’s slip rolls combine precision-turned, ground and polished high carbon steel rolls with heavy-duty, cast iron end frames and a welded steel base to make an accurate and durable forming tool. Convenient operating features include large roll adjusting screws, scales for speeding repeat set-up, and a front-mounted handle to lift the upper roll for material removal. Wire grooves are standard.
Capacity, Mild Steel: 16 Gauge
1.6 mm
Maximum Forming Length: 49 in.
1244 mm
Diameter of Rolls: 3 in.
51 mm
Minimum Forming Radius: 1-1/2 in.
38 mm
Wire Grooves: 3/8, 1/2, 5/8 in.
9.5, 12.7, 15.8 mm
Dimensions, L x W x H: 77 x 30 x 22 in.
1956 x 762 x 559 mm
Shipping Weight: 1100 lbs.
500 kg
