Ideal to make Ogee Bead, Turning, Wiring, Crimping, Burring, Elbow Edging,Single Bead, flange, slitting , flattening, offset
ISO 9001 certified
Heavy Duty cast iron construction
(4) sets of standard dies
S1 – Shear die
S2 – Step die (10mm)
S3 – Bead die (R6mm)
S4 – Step die (8mm)
S1 – Shear die
S2 – Step die (10mm)
S3 – Bead die (R6mm)
S4 – Step die (8mm)
Easy adjustment and operation
Ideal to make Ogee Bead, Turning, Wiring, Crimping, Burring, Elbow Edging, Single Bead, flange, slitting, flattening, offset
Product description
Max Capacity
Mild Steel
Stainless Steel: 8 Ga.
12 Ga.
Throat Depth: 12″
Cylinder Length: 9″
Cylinder Speed: 15 RPM
Main Motor: 3 HP 3 Phase
Prewired: 220VAC
Optional: 440VAC
Overall Dimensions (LxWxH): 61″ x 20″ x 50″
Machine Weight: 770 lbs.
Optional die set (extra): $475.00
Custom profile die set: $575.00
