In ERFOLD CNC control system, each side bend is programmed individually and profile view of the side is shown on the screen after each bend is programmed.
Each process type on the sides (normal bend,hemming,large radius etc.) is defined,and bending/process length is entered numerically. Application Areas
Stainless furniture / trims
Panels
Metal architectural accessories and illumination covers
Electrical cabinets and panels
Professional kitchen equipments
Product description
Sheet length: 2300
Maximum material length: 2300
Maximum material width: 1500
Maximum bend height/depth: 254
Minimum bending size (4 sides): 410 x 410
Minimum bending size (1 side): 210
Minimum bending radius: 1.2
Twisting speed: 0.5
Pressure clearance: 265
Maximum bending angle: +/- 145°
Minimum bending diameter: Steel: 1.5
Stainless steel: 1: Stainless steel: 1
Aluminum: 2: Aluminum: 2
Software: ERFOLD
Number of axis: 11
Machine dimensions: 5000
Width: 3915
Height: 2850
Machine weight: 15000
