Product description
Capacity: 24 to 28 gauge material.
Speed: 35 fpm.
Motor: Energy efficient, 1/2 H.P., 115/208-230V, 5.4 AMPS, 60 cycle, single phase, A.C., 1800 R.P.M.,
Auto over-load protector.
Housing: Heavy gauge, spot welded steel enclosure with a primed and baked-on enamel finish.
Dimensions: 32″ long, 16 3/4″ wide, 9 1/16″ high (work surface), 13 1/4″ high (cover guard). Work
surface is ” high when equipped with optional “E-Z MOVE” drop-in floor stand.
Weight: Shipping weight, without optional floor stand, is approximately 109 pounds or 139 pounds with
stand.
General: All forming head components are precision crafted using case hardened steel and needle
bearings throughout. Exclusive tuck-away power cord for easy portability.
