Designed specifically for the CNC, CAD and Pattern Making industries, The Logic Trace Digitizing System consisting of a digitizing tablet, pen and Logic Trace software can quickly and easily trace any outline, template, object, or part and create a DXF graphics file on your computer ready for use by any CNC, CAD or cutting software and machine. A separate windows-based computer is required for operation and use. Not compatible with Linux-based computers.
Product description
Most commonly requested board sizes are 44″x60″ (110x150cm) and 5’x8′ (1.5×2.4m) but we also have smaller and larger boards. Accuracy is 0.01″ and 0.005″.
Works with all machines: plasma cutters, waterjets, laser cutters, vinyl cutters, plotters, any and all CNC machines.
Works with all software: Autocad, Plasmacam, Mastercam, Mach3, Bobcad, Vectric, Vcarve, SigmaNest, Solidworks, Rhino, CorelDraw, Adobe Illustrator, Gerber and many others. Our DXF files are compatible with all CNC and CAD software
Very easy to use, takes less than ten minutes to learn.
