Manual double self-centering vise assures burr-free cuts
Operator controlled trigger switch
Miter locking device stops: 45 degree left, 90 degree and 45 degree right
Capable of slotting
Double reduction, hardened and ground worm and wheel gear box
Chip drawer
7 Gallon flood coolant tank with pump
One 250 mm diameter HSS blade
One blade wrench
One gallon coolant
Complies with ANSI B11.10 safety standards
Warranty: Three years on parts
Made in USA
Product description
Cutting Speeds
(specify when ordering): Motor rate:
2 hp
HT(High Turn) – designed for thin wall tube 0.060 wall thickness or thinner and non-ferrous material: Motor rate:
1.5 hp
SS(Single Speed) – designed for 220v 1ph applications: Motor rate:
2 hp
Maximum Cutting Capacities
(with 275 mm blade): 45 Degree
2″
2″ x 2″
2″ x 2″
SOLID
Round
Square: 45 Degree
1″
1″ x 1″
