Product description
Roll Adjustment: Hydraulic Driven
Dia. of roller: 7.5″
Dia. of roller shaft: 2″
Roller speed: 16 RPM
Main Motor: 3 HP 220VAC 3 Ph.
(Optional 440VAC)
Dimensions: 40″ x 35″ x 65″
Weight: 1,120 LBS
Oil Tank Capacity
(only fill up 90%): 7 Gal.
Recommended Hydraulic Oil: Texaco-Rando HD-68 Hydraulic Oil
Shell AW-68 Hydraulic Oil
TUBE ROLL SETS:: TUBE ROLL SETS:
34T-PRB55: ¾”
1T-PRB55: 1”
114T-PRB55: 1-1/4”
112T-PRB55: 1-1/2”
2T-PRB55: 2”
212T-PRB55: 2-1/2”
PIPE ROLL SETS:: PIPE ROLL SETS:
34P-PRB55: ¾”
1P-PRB55: 1”
114P-PRB55: 1-1/4”
112P-PRB55: 1-1/2”
2P-PRB55: 2”
212P-PRB55: 2-1/2”
