52″ Hydraulic Metal Shear – 1/4″ Shearing Machine

ISO 9001 certified
1-Year parts only warranty
Taiwan machines
24” SIKO Front Operated power back gauge w/ micro adjustment 0.004” inch/mm digital display
Quick Change Blade Gap Adjustment (BGA), with gap dial
CE standard “OMERO” electric control system
Meet OSHA safety standard code
Shadow line for accurate straight cutting
Adjustable cutting length and stroke
Ball transfer plates on worktable for easy loading workpiece
Well balanced and sturdy all steel machine frame
German made Hydraulic logic system centrally located and quiet
Hydraulic hold-downs with anti-mar neoprene
Shear blades are high grade carbon/chrome alloy steel and hardened to 60 HRC

2-edge indexable top blade
2-edge indexable bottom blade
2-edge indexable top blade
2-edge indexable bottom blade
Full length viewable safety finger guard to protect operator from cutting hazard
Removable safety foot pedal, automatic blade raise up on removal of foot from pedal
Hydraulic, electrical overload protection
Compact operator control panel
All motors are overload protected & low voltage control system
Jog or continuous auto cycle cutting operation modes
Product description

Cutting capacity:
Mild steel
Stainless steel: 6’ x ¼”
6’ x 10 Ga.
Blade length: 6’6″
Strokes per minute: 10-17
Throat depth: 18″
Worktable height: 34 1/2″
Front support arm: 24″
Back gauge for E model: 36″ powered B.G.
Blade rake angle: 2 degree
Oil tank cap.: 2117L = 31 Gal
Main Motor

Powered B.G. Motor: 15 HP, 220V/50A
440V/25A

1 HP
Machine weight: 7,650 LBS
Machine dimmensions: 102″ x 89″ x 63″
