Two full stroking hydraulic vises
Select left or right side control panel
Powered movable guide arm
7.5 HP VFD. True direct blade drive – no belts/pulleys
Hydraulic positive down feed
Cast iron band wheels
Automatic programmable mitering with “go to” angle functionality from 45° left to 45° right
Replaceable blade brush
Robust steel base
Easy access electrical panel and hydraulics
Blade breakage switch
Hydraulic band tensioning with digital readout
Replaceable carbide guide inserts
90° straight head
2 HP hydraulic pump provides system pressure
Safety door interlocks
Flood coolant with wash down hose
Laser light
Work light
Variable vise pressure
Product description
Technical Specifications: Technical Specifications
Capacity: Round
90°: 18” with tall vise
90° Canted Head: 18” with tall vise
90° with OH Bundling: 12”
45°: 12”
45° Canted Head: 12”
45° with OH Bundling: 12”
Blade Size: 8 Gallons
Blade Drive: 4,800 lbs.
Motor Voltage: 44”
Blade Speed: 98” x 120” x 123”
Coolant Tank Capacity: 45° left to 45° right
