Single Operator, 5 Stations
Rectangular Notcher: 2-1/2″ x 2-3/4″ x 3/8″
50 Ton Punch Station (1-1/4″ in 1/2″)
Tool Table Work Area
Keyed Punch Ram For Safety
Slug Receptacle
6″ Throat Depth
Electrical Box Supplied With Emergency Palm
2″ Die Holder, Punch Nut W/Wrench & Stripper Button And Lock-Out Tag-Out Accommodations
One Round Punch & Die: Max Diameter 1″ * 230/460 Volt / 3-Ph Electrics (Must Specify)
Adjustable Electric Stroke Control w/Scale
All Guards Comply With ANSI B 11-5 Standards
Electric Remote Foot Pedal
Forklift Accommodations
Angle Shear Capacity: 4″ x 4″ x 3/8″ At 90° and 2″ x 2″ x 1/4″ At 45°
14″ Flat Bar Shear With 4-Way Reversible Blade
Three-year warranty (Parts only)
Made in the USA
