Universal for Various Pipes: Capable of cutting round pipes, square pipes, rectangular pipes, channel steel, angle steel, I-beams, and other profiled steel.
| Effective Cutting Length of Pipe | 255.9" | 6,499.9 mm |
| Wattage | 6,000 W | 6,000 W |
| Laser power (Optional) | 3000W / 6000W | 3000W / 6000W |
| Clamping Range | Round pipe Φ20-350mm; Square pipe 口20-250mm; I-beams 10#-22# | Round pipe Φ20-350mm; Square pipe 口20-250mm; I-beams 10#-22# |
| Max. Rotation Rate | 60 r/min | 60 r/min |
| Single Pipe Load-Bearing | 1,102.3 lb | 500 kg |
| Chuck Structure | 360 Pneumatic Chuck | 360 Pneumatic Chuck |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR - Parts
Machine Photo May Include Optional Equipment
Product image is only a representation, actual product appearance may differ slightly
OPTIONAL ITEMS - CALL FOR PRICE:
Fully automatic loading machine
Semi-automatic loading machine
Follow-up Unloading Rack
Bevel cutting head
