Specifications
Max sheet size: 240 x 96 in
Positioning accuracy of X/Y axes: ±0.05 mm
Positioning repeatability of X/Y axes: ±0.03 mm
Max idle speed: 120000 mm/min
Max travel acceleration: 1.5 G
Max load capacity: 13333 lb
Nominal power output: 2.0 kW
Power consumption: 15.0 kW
Source brand: MAX Photonics and Raycus as available options for selection
Power supply: ~3x480 V 60 Hz or other
Ingress protection rating: IP54
Max cutting thickness
Mild steel: 8 mm
Stainless steel: 5 mm
Aluminum: 3 mm
Brass: 2 mm
Note: Images provided in the quote are for reference only, and the actual machines may appear differently.
