Stable and reliable structure
The Y-axis uses four 45mm high-rigidity and high-load roller linear guideways and heavy-duty 8-slide blocks to enhance rigidity and load-bearing capacity.
Convenient and efficient chip handling: The machine is equipped with two screws as standard to effectively discharge the chips generated during processing, with high conveying efficiency.
Closed spindle box
The spindle box adopts a closed box structure, the contact size with the column guideway is enlarged, and the overall lightweight design. The short nose spindle is standard, which improves the Z-axis positioning accuracy and spindle processing stability during the machine tool processing.
Stable and reliable tool changing device
The SV series is equipped with a disc manipulator tool changer as standard, achieving higher tool change efficiency and shortening non-cutting time.
The solid dense-baked casting and integral box-type bed and arched column structure improve the basic rigidity of the machine.
The standard fully enclosed tool chamber design eliminates the impact of cutting fluid and iron chips on the tool holder during continuous processing, effectively improves the stability of tool changing action, reduces maintenance costs, and greatly improves productivity.
The large-capacity tool magazine can clamp multiple tools at one time, and there is no need to add tools when processing workpieces, which greatly saves cutting time.
X/Y/Z axis travel: 1300/700/650mm
Distance from column to spindle center: 762mm
Distance from table surface to spindle nose: 200-850mm
Worktable size: 680x1500mm
T-slot size: 5-18*125mm
Max. load bearing of worktable
Length: 800kg
Spindle hole taper: BT40
Main motor power: 11/15KW
Spindle speed: 10000(Belt)rpm
Max. feed speed: 12000mm/min
Rapid feed speed: 30/36/24m/min
Tool magazine capacity: 24T
Max.Tool change time: 2.5S
Machine dimension: 3550*2800*3060mm
Machine weight: 8000kg
