NEW VICTOR MACHINES DCM-5TS

FEATURES:
Machine frame is completely enclosed steel construction. Sturdiness design guarantees highest efficiency and quiet operation
4-way tilting heavy cast iron table with T-slot
2-speed transmission is powered by enclosed gears running in continuous bath of oil with infinite vari-speed control unit
Convenient blade speed tachometer display
Easy quick adjustable blade guides firmly support blade
Upper / lower V-type saw guide with ground carbide inserts corresponding to blade size in use. Air nozzle blows off chips as in sawing
Butt welder and annealing unit provides easy welding work
Built-in work light

STANDARD ACCESSORIES:
Saw blade cutter
Saw blade welder
Saw blade grinder
LED blade speed display
Air nozzle
Halogen work light
Standard saw blade - 1 piece
Rip fence for straight cutting
Miter protractor for angular cutting

Type: Vertical Bandsaw (with T-slot Table)
Throat capacity: 19.625"
Max. thickness: 11.00"
Table size: 23.50" x 19.50"
Table inclination (4-way): 15°
Speed: Low 65 ~ 280 fpm / High 400 ~ 1,640 fpm (98 ~ 2,300 fpm optional high speed)
Length: 153"
Width: 1/8" ~ 5/8"
Butt welder capacity: 1/8" ~ 5/8"
Main motor: 2 HP 3 Phase
Dimensions (LxWxH): 51" x 30" x 85"
Net weight: 960 lb.
Gross weight: 1,125 lb.
