Work-Tank size (W x D x H): mm 1,130x690x550
Work table size (X x Y): mm 750x480
X x Y axes travel: mm 500x400
Z axis travel (by AC Motor): mm 400
U x V axes travel (under 50mmH.): mm 30x30
Max. work-piece thickness: mm 400
Max. work-piece size (W x D x H): mm 500x400x400
Max. work-piece weight: kgs 400
The wire bobbin travel: mm 230
Dia. of molybdenum wire: mm Ø0.18
Maximum taper angle: Degree 6 degree under 50mm high
Packing dimensions (W x D x H): mm 775x730x1,940
Net weight: kgs 200
Capacity of dielectric fluid: l 100
Dielectric fluid tank size (W x D x H): mm 1000x290x340
Machining average current: A 5
Cutting speed: mm2/min 100~180
Cutting accuracy: mm ±0.015
Best finish roughness: µm RA 1.0
Max. power consumption: KVA 3.0
External dimensions (W x D x H): mm 660x610x1,700
Circuit system: Power MOS transistor
Average output current: 5A
Voltage select: Automatic switching.
IP select: 1-10 steps
Off time select: Automatic switching.
Data input: USB, RS-232C, internet.
Positioning display: 15" LCD TFT
Cutting data display: 5" LCD TFT
Graphic function: 2D/3D display
Control system: Open Loop/Stepping system
Control axis: X,Y,U,V. (4 axes)
Minimum moving unit: 0.001mm
Minimum setting unit: 0.001mm
Max. command value: ±9999.999mm
Interpolation: Linear / Circular
Command system: Abs. / Inc.
Total AC power input: (Ø110V or Ø220V) 3KVA
