Machining method: Submerge / Flushing
Max. workpiece size (W x D x H): mm 680x420x150
Max. workpiece weight: kg 250
X, Y axes travel: mm 300x200
Z axis travel: mm 150
U, V axes travel: mm ±30x±30
X-Y axes feed rate: mm/min Max. 900
Best surface roughness: µm Ra 0.65
Drive motor (X, Y, U, V): AC Servo Motor
Wire diameter (standard): mm Ø0.25 (Ø0.15-Ø0.3)
Wire feeding speed: m/min 0-15
Wire tension: gf 200-2500
Max. taper angle: degree ±15°/80
Max. wire bobbin weight: kg 6
Outside dimensions (W x D x H): mm (S)850x573x375 (F)920x573x400
Machine weight: kg 1500
Tank capacity (liter): l 480 / 420
Filter element: Paper filters
Ion exchange resin: l 15l
Conductivity control system: Standard
Fluid temperature control (With coolant): Auto. (optional)
Outside dimensions (W x H x D): mm 600x870x1850
Net weight (without water): kg 200
Circuit system: Power MOS transistor
Max. outpt current: A 25
Voltage select: V 145
IP select: 10
Off time select: 50
I/O device: Keyboard, RS-232C, CF CARD
Display type: 15"LCD-TFT
Control system: 32 bit, 1-CPU, closed loop software servo system
Control axis: X, Y, U, V, Z
Min. setting unit: mm 0.001
Max. command value: mm ±9999.999
Interpolation: Linear / Circular
Command system: Abs. / Incl.
Machining feed control: Servo / Const. Feed
Scaling: 0.001~9999.999
Auto 2nd cut system: Re-trace and auto changed machining data
Machining condition memory: 0-9999
Total AC power input: KVA 3Ø220V ±10% / 13KVA
