The manufacturer reserves the right to modify the design, specifications, mechanisms…etc. to improve the performance of the machine without prior notice. All the specifications shown above are just for reference.
Table size: mm (inch) 400x800 (16"x32")
Max. grinding surface: mm (inch) 400x800 (16"x32")
Max. distance center of spindle to table: mm (inch) 550 mm (22") [650 mm (25"), Opt.]
Table speed: m/min ("/min) 5~25 M/min (200"~1000"/min)
Table guideway: V & Flat way
Auto. cross feed increment: approx. mm (inch) 0.5mm~20mm (0.02"~0.8")
Rapid power cross feed approx.: mm/min ("/min) 1100 mm/min (44"/min) (60Hz) 900 mm/min (36"/min) (50Hz)
Cross feed on hand wheel: 1 rev 1 gra 5 mm (0.2") 0.02 mm (0.001")
Rapid power head elevation approx. (Option): 60Hz 50Hz 550 mm/min (13"/min) (60Hz) 450 mm/min (11"/min) (50Hz)
Vertical feed on hand wheel: 1 rev 1 gra 2 mm (0.05") 0.01 mm (0.0002")
Auto. down feed: (Option) 0.001 mm~0.999 mm/Time (0.0001"~0.0999"/Time, Opt.)
Wheel speed: 60Hz/50Hz 1750 R.P.M. (60Hz) / 1450 R.P.M. (50Hz)
Wheel dimension: mm (inch) 406x50x127 mm (16"x2"x5")
Spindle motor: HP 5HP
Hydraulic pump motor: HP 2HP
Auto. cross feed motor: HP 1/5HP
Rapid head elevation motor: HP 1/5HP (Opt.)
Machine net weight: kgs (Lbs) 3250 (7150 Lbs)
Packing gross weight: kgs (Lbs) 3500 (7700 Lbs)
Machine floor space: mm (inch) 3000x2000 (118"x79")
Packing dimensions (LxWxH): cm (inch) 276x228x215 (109"x90"x85")
