High rigidity, high efficiency and high stability structural design
Hot sale 10000+ units
Excellent overall performance, high cost performance
The unique arc-shaped base design after finite element analysis and the internal reinforcement rib layout provide better processing rigidity among machine tools of the same size.
The base adopts a large-span structure with two 45mm roller linear guideways, which provides the machine with very strong load-bearing capacity while meeting the high rigidity requirements during heavy cutting.
High performance spindle
The spindle box guideway is designed with a large cross-section and the structure is optimized to be the best among similar models. It is equipped with a Z-axis weightless structure to ensure the stability and accuracy of vertical high-speed positioning.
The Z-axis guideway span is larger than that of traditional models, which greatly improves the contact ratio between the spindle box and the column, ensuring high torque of the spindle during processing.
The short nose spindle ensures the cutting rigidity of the machine.
Superior processing capabilities
The VMC series machine tools with stable cutting performance are suitable for automotive parts, 3C industry, military industry, molds, sewing equipment and diversified product processing applications in the ever-changing market.
X/Y/Z axis travel: 850/550/650mm
Distance from column to spindle center: 610mm
Distance from table surface to spindle nose: 125-775mm
Worktable size: 550x1000mm
T-slot size: 5-18*100mm
Max. load bearing of worktable
Length: 700kg
Spindle hole taper: BT40
Main motor power: 11/15KW
Spindle speed: 8000(belt)rpm
Max. feed speed: 10000mm/min
Rapid feed speed: 12/12/12m/min
Tool magazine capacity: 24T
Max.Tool change time: 2.5S
Machine dimension: 2700*2510*3000mm
Machine weight: 6200kg
