Closed spindle box
The spindle box adopts a closed box structure, which increases the contact size with the column guideway and adopts a lightweight design as a whole. In addition, the short nose spindle is standard, which improves the Z-axis positioning accuracy and spindle processing stability during the machine tool processing.
X/Y/Z axis travel: 1400/700/700mm
Distance from column to spindle center: 766mm
Distance from table surface to spindle nose: 150-850mm
Worktable size: 700x1600mm
T-slot size: 5-18*125mm
Max. load bearing of worktable
Length: 1100kg
Spindle hole taper: BT50
Main motor power: 15/18.5(wide area)KW
Spindle speed: 6000(belt)rpm
Max. feed speed: 12000mm/min
Rapid feed speed: 24/24/20m/min
Tool magazine capacity: 24T
Max.Tool change time: 3.5S
Machine dimension: 4850*2955*3320mm
Machine weight: 10000kg
