Increased Span and Width Saddle
The hollow structure with a reasonable tendon type, has the characteristics of high rigidity and high stability, the best center symmetrical spindle design, the increased scraping contact area, the high -strength side pressure plate is locked, which has high rigidity and high thermal stability.
Horizontal Stepped Guideway Bed
To provide a reliable foundation for lathes, high rigidity, high precision, and high stability.
Max. Swing Over Bed: Φ610mm
Max.Turning Length: 565mm
Max.Turning Dia: Φ450mm
Max. Swing Over Carriage: Φ400mm
X/Z Axis Travel: 240/610mm
Spindle Hole Taper: A2-6
Max. Passing Bar Dia.: Φ50mm
Spindle Speed Range: 50-4500rpm
Power: 11/15kW
Standard Chuck Dia.: 8'' inch
Rapid Feed Rate: 30/30m/min
Tailstock Spindle Taper: 5#
Standard Turret: 12T(Servo)
Nearby Tool Select: Yes
Machine dimension: 2950*1700*1865mm
Machine weight: 4700kg
