ITEM: ML-800S ML-800SY ML-800M ML-800MY ML-800L ML-800LY
Swing Over bed: Ø800
Swing Over Saddle: Ø600 Ø500 Ø600 Ø500 Ø600 Ø500
Max. Machining Dia.: Ø620 Ø600 Ø620 Ø600 Ø620 Ø600
Max. Machining Length: 1,000 mm 2,000 mm 3,000 mm
X-axis: 340(310+30) mm
Z-axis: 1,150 mm 2,150 mm 3,150 mm
C-axis (Optional): – 360˚ (0.001˚) – 360˚ (0.001˚) – 360˚ (0.001˚)
Tool Capacity: 12 pcs
Chuck Diameter: STD: 15”
OPT: 12” /15”(Oversize)/18”
Spindle Speeds: STD: 2,000 rpm (15”)
OPT: 2,500 rpm (12”) /1200 rpm (15”) /1,000rpm (18”)
Spindle Nose: STD: A2-11
OPT: A2-8/A2-15
