Swing Over Bed: Ø600
Swing Over Saddle: Ø450
Max. Machining Dia.: Ø420
Max. Machining Length: STD: 560 mm (8”)
OPT: 540 mm (10”)
Draw Bar Dia.: STD: Ø52
OPT: Ø75
X-axis: 230 (210+20) mm
Y-axis: –
Z-axis: 590 mm (10”)
600 mm (8”)
Tool Capacity: STD: 10 pcs
OPT: 12 pcs
Chuck Diameter: STD: 8″
OPT: 10″
Spindle Speeds: STD: 50–4,500 (A2-6)
OPT: 50–3,500 (A2-8)
Spindle Nose: STD: A2-6
OPT: A2-8
