Swing Over Bed: Ø600
Swing Over Saddle: Ø450
Max. Machining Dia.: Ø420
Max. Machining Length: STD: 475 mm (8”)
OPT: 565 mm (10”)
Draw Bar Dia.: STD: Ø52
OPT: Ø75
X-axis: 230 (210+20) mm
Y-axis: –
Z-axis: 600 mm
Tool Capacity: STD: 10 pcs
OPT: 12 pcs
Chuck Diameter: STD: 8″+6”(W)
OPT: 10”+6”(W)
Spindle Speeds: Main Spindle:
STD: 50–4,500 (A2-6)
STD: 50–3,000 (A2-8)
Sub Spindle: 6,000 (A2-5)
Spindle Nose: Main: A2-6
STD: A2-8, A2-6 (Built-in)
Sub: A2-5
