Swing Over Bed: Ø600
Swing Over Saddle: Ø450
Max. Machining Dia.: BMT65: Ø380
VDI40: Ø285
Max. Machining Length: BMT65: STD: 480 mm (8”) / OPT: 470 mm (10”)
VDI40: STD: 520 mm (8”) / OPT: 510 mm (10”)
Draw Bar Dia.: STD: Ø52
OPT: Ø75
X-axis: BMT65: 206 (190+16) mm
VDI40: 206 (142.5+63.5) mm
Y-axis: 100 (50+50) mm
Z-axis: BMT65: 525 mm
VDI40: 565 mm
Tool Capacity: 12 pcs
Chuck Diameter: STD: 8″
OPT: 10″
Spindle Speeds: STD: 50–4,500 (A2-6)
OPT: 50–3,500 (A2-8)
Spindle Nose: STD: A2-6
OPT: A2-8, A2-6 (Built-in)
