Swing Over Bed: Ø600
Swing Over Saddle: Ø450
Max. Machining Dia.: BMT65: Ø380
VDI40: Ø285
Max. Machining Length: BMT65: STD: 720 mm (10”) / OPT: 700 mm (12”)
VDI40: STD: 760 mm (10”) / OPT: 740 mm (12”)
Draw Bar Dia.: STD: Ø75 (10”)
OPT: Ø78 (10”) / Ø91 (12”)
X-axis: BMT65: 206 (190+16) mm
VDI40: 206 (142.5+63.5) mm
Y-axis: 100 (50+50) mm
Z-axis (Optional): BMT65: 765 mm
VDI40: 805 mm
Tool Capacity: 12 pcs
Chuck Diameter: STD: 10″
OPT: 12″
Spindle Speeds: STD: 50–3,500 (A2-8, 75 mm, 10”)
OPT: 50–3,000 (A2-8, 78 mm, 10”)
50–2,500 (A2-8, 91 mm, 12”)
Spindle Nose: A2-8
