Swing Over Bed: Ø600
Swing Over Saddle: Ø450
Max. Machining Dia.: Ø420
Max. Machining Length: STD: 780 mm (10”)
OPT: 760 mm (12”)
Draw Bar Dia.: STD: Ø75 (10”)
OPT: Ø78 (10”) / Ø91 (12”)
X-axis: 230 (210+20) mm
Y-axis: –
Z-axis (Optional): 830 mm (10”)
820 mm (12”)
Tool Capacity: STD: 10 pcs
OPT: 12 pcs
Chuck Diameter: STD: 10″
OPT: 12″
Spindle Speeds: STD: 50–3,500 (A2-8, 75 mm, 10”)
OPT: 50–3,000 (A2-8, 78 mm, 10”)
50–2,500 (A2-8, 91 mm, 12”)
Spindle Nose: A2-8
