NEW INGENIOUS MACHINERY OPT: LS-120, LS-120SV LS-120SP OPT: LS-120 (8T)

NEW INGENIOUS MACHINERY OPT: LS-120, LS-120SV LS-120SP OPT: LS-120 (8T)

Safety note

Buying from non-Pro sellers
Non-Pro sellers can be individuals or smaller businesses. Equipt does not verify every seller or inspect every item. Confirm who you're dealing with, ask for recent photos or video, and only pay through secure, traceable methods.

This seller is not an Equipt Pro dealer. Equipt does not inspect items, handle payment or guarantee transactions. Verify the seller and equipment before sending funds.

How to stay safe with non-Pro sellers

Equipt connects buyers and sellers of industrial equipment. We don't own the machines, inspect them in person or process payment for you, so it's important to do your own checks—especially with sellers who are not using Equipt Pro.

Before you commit:
  • Confirm the seller's business name, address and contact details
  • Ask for recent photos or video of the equipment running, including serial plates
  • Request invoices, maintenance records or proof of ownership when appropriate
  • Compare pricing against similar listings to spot offers that look too good to be true
When paying:
  • Use secure, traceable payment methods (no cash or untraceable transfers)
  • Be cautious if a seller pressures you to move very fast or change payment details last minute
  • If anything feels off, pause the transaction and contact Equipt support before proceeding

Taking a few extra steps up front greatly reduces the risk of scams and helps keep the Equipt marketplace safe for everyone.

Overview
Type:
CNC Lathes
Manufacturer:
INGENIOUS MACHINERY
Model:
OPT: LS-120, LS-120SV LS-120SP OPT: LS-120 (8T)
Stock #:
8167057
Specifications

ITEM: UNIT ML-430 ML-430Y
Standard: C axis
Swing over bed: mm Φ430 Φ430
Swing over saddle: mm Φ160 Φ160
Maximum machining diameter: mm Φ430 Φ430
Maximum machining length: mm 240 Gang tool: 240
Axial live tooling: 110
Radial live tooling: 130
Slant angle of bed: ° 0° 0°
X-axis: mm 350 350
Z-axis: mm 320 320
Y-axis: mm – 165
C-axis: mm – 360° (0.001°) 360° (0.001°)
Spindle speeds: rpm 6,000 6,000
Spindle nose: A2-5 A2-5
Spindle bore diameter: mm Φ56 Φ56
Front bearing inner diameter: mm Φ80 Φ80
Draw bar diameter: mm Φ45 Φ45
Chuck diameter: inch STD: 6″ STD: 6″
Type: Gang type Live-tooling (VDI20) STD: Power tool;
OPT: Hydraulic/Servo turret
Stations: pcs STD: 6(gang tool); OPT: 8 12 5 (Power tool)
Tool specification for Y axis: – – ER16M
Square tool shank: mm 20 x 20 16 x 16 20 x 20
Boring bar shank diameter: mm Φ25 Φ20 OPT: Φ25
Indexing time (0~180°): sec LS-120: 1.8; LS-120SV: 0.9 0.83 LS-120: 1.8; LS-120SV: 0.9
Spindle Speeds: rpm – 50~5,000 50~5,000
Rapid Traverse: m/min X:30, Z:30 X:30, Y:18, Z:30
Main-spindle: kw STD: ß6 (5.5/7.5) ; OPT: α6 (5.5/7.5) STD: ß6 (5.5/7.5)
Live-tool: kw – α1.5/10000 (2.2/3.7) ß4 (0.75)
(for Y axis power tool)
Axis servo motor: kw STD: X/Z- ß8 (1.2); OPT: X/Z – α8 (1.6) X/Y/Z – ß8 (1.2)
Hydraulic oil pump: kw 0.75 0.75
Coolant pump: kw 0.53 0.53
Positioning: mm ±0.003 ±0.003
Repeatability: mm ±0.003 ±0.003
Requirements: KVA 380-415/220V 12KVA 380-415/220V 15KVA
Height: cm 212 212
Floor space (WxD): cm 210 x 203 210 x 203
Packing: cm 242 x 230 x 212 242 x 230 x 212
Net weight: kg 3,000 3,000
Gross weight: kg 3,150 3,150
