NEW INGENIOUS MACHINERY STD: LS-320; OPT: LS-320SV STCI4032-W2- SMHDT32-460-530

NEW INGENIOUS MACHINERY STD: LS-320; OPT: LS-320SV STCI4032-W2- SMHDT32-460-530

Safety note

Buying from non-Pro sellers
Non-Pro sellers can be individuals or smaller businesses. Equipt does not verify every seller or inspect every item. Confirm who you're dealing with, ask for recent photos or video, and only pay through secure, traceable methods.

This seller is not an Equipt Pro dealer. Equipt does not inspect items, handle payment or guarantee transactions. Verify the seller and equipment before sending funds.

How to stay safe with non-Pro sellers

Equipt connects buyers and sellers of industrial equipment. We don't own the machines, inspect them in person or process payment for you, so it's important to do your own checks—especially with sellers who are not using Equipt Pro.

Before you commit:
  • Confirm the seller's business name, address and contact details
  • Ask for recent photos or video of the equipment running, including serial plates
  • Request invoices, maintenance records or proof of ownership when appropriate
  • Compare pricing against similar listings to spot offers that look too good to be true
When paying:
  • Use secure, traceable payment methods (no cash or untraceable transfers)
  • Be cautious if a seller pressures you to move very fast or change payment details last minute
  • If anything feels off, pause the transaction and contact Equipt support before proceeding

Taking a few extra steps up front greatly reduces the risk of scams and helps keep the Equipt marketplace safe for everyone.

Overview
Type:
CNC Lathes
Manufacturer:
INGENIOUS MACHINERY
Model:
STD: LS-320; OPT: LS-320SV STCI4032-W2- SMHDT32-460-530
Stock #:
8167056
Specifications

ITEM: UNIT ML-850
Standard: C axis
Swing over bed: mm Φ850
Swing over saddle: mm Φ600
Maximum machining diameter: mm Φ720 / Φ600 Φ620 / Φ600
Maximum machining length: mm STD: Φ720 x 150 +
Φ600 x 1,100 620 x 190 +
Φ600 x 1,030
Slant angle of bed: 45°
X-axis: mm 380 (360+20) 380 (310+70)
Y-axis: mm – –
Z-axis: mm 1,330 1,290
C-axis: ° – 360° (0.001°)
W-axis: mm –
Spindle speeds: rpm 50~2,000 (4-step gear box)
Spindle nose: STD: A2-11
Spindle bore diameter: mm STD: Φ134 (A2-11)
Front bearing inner diameter: mm STD: Φ180 (A2-11)
Draw bar diameter: mm STD: Φ116; OPT: Φ120
Chuck diameter: inch STD: 15″; OPT: 18″
Type: Automatic
Stations: pcs STD: 12
Square tool shank: mm 32 x 32
Boring bar shank diameter: mm Φ50
Indexing time (0~180°): sec 3.2 2.71
Spindle Speeds: rpm – 50~3,500
Rapid Traverse: m/min X: 12, Z: 20
Quill diameter: mm Φ125
Quill bore taper: MT5
Quill travel: mm 160
Tailstock travel: mm 1,320
Main-spindle: kw STD: α22 (22/26); OPT : α30 (30/37)
Sub-spindle: kw –
Live-tool: kw – α12/8000/ (11/15)
Axis servo motor: kw X/Z- α22 (4.0)
Hydraulic oil pump: kw 2.25
Chip conveyor: kw 0.2
Coolant pump: kw 0.8
Positioning: mm ±0.005
Repeatability: mm ±0.004
Requirements: KVA 380-415/220V; STD: 30 KVA; OPT: 40 KVA
Height: cm 250
Floor space (WxD): cm 529 x 218
Packing (w/conveyor): cm 607 x 229 x 256
Net weight (w/conveyor): kg 11,820
Gross weight (w/conveyor): kg 12,600
