Overview
Type:
CNC Lathes
Manufacturer:
ACCUWAY
Model:
UT-300S UT-300SM
Stock #:
8142197
Description

Slant Bed Turning Center

STANDARD ACCESSORIES
FANUC 0i-T controller
RJ-45 interface
Rigid tapping
Heat exchanger for electric cabinet
10.4" Colored LCD monitor
Lubrication system
4-bar coolant system
Three-color warning light

OPTIONAL ACCESSORIES
Upgrade to 15" Colored LCD monitor
Collect chuck
Tool setter
Parts catcher and parts conveyor
Bar feeder interface (7 or 24 pins)
Bar feeder
Oil mist collector
Oil-coolant skimmer
Air cooler for electric cabinet
Gear box
Transformer
CE version
Linear scale
0 degree rotary tool holder(UT-300SM)
90 degree rotary tool holder(UT-300SM)

Specifications

Controller: FANUC 0i-T
Swing over bed: mm 612 700
Swing over saddle: mm 400 500
Max. turning diameter(SP1): mm 500 480
Max. turning diameter(SP2): mm 400 375
Max. turning length: mm 610 540 540 470
Guide way type: Box
Spindle nose taper: ASA A2-5 A2-5
Chuck diameter: inch 6 8 6 8
Bar capacity: mm 44 44
Spindle speed: rpm 6000 5000 6000 5000
Spindle motor power(Cont. / 30min): kW 5.5/7.5
X-axis Travel: mm 300 280
Z-axis Travel: mm 750 750
B-axis Travel: mm 700 700
X-axis Rapid Traverse Rate: m/min 20 20
Z-axis Rapid Traverse Rate: m/min 24 24
B-axis Rapid Traverse Rate: m/min 20 20
Tooling system: BOT BMT-65
Turret driven type: Hydraulic Servo mechanical
Number of tools: station 12 12
Square tool shank size: mm 25 25
Round tool shank size: mm 40 40
Machine dimension L x W x H: m 3.5 x 1.8 x 1.9 3.5 x 1.9 x 2
Net weight: kg 5900 6000
