The rotary motor in the grinding spindle base adopts DD motor for driect drive, achieving no backlash, high speed and high precision rapid rotary positioning.
Feed guideway for the grinding wheel base uses optimized rectangular design with the concept of full enclosure to allow highly rigid and precise machining performance.
Grinding wheel drive motor utilizes highly efficient and high torque motor to demonstrate heavy-duty cutting ability and highly efficient grinding capability.
Choose the best combination of grinding wheel package to enable compound grinding and multiple machining procedures with just one clamping, showing high speed, high precision and high efficiency capabilities.
Swing over table(mm): Ø350
Distance between centers(mm): 1,000
Max. outer grinding wheel dimension(mm): Ø510 / Ø510
Machine Dimension (WxDXH mm): 4,200 x 2,000 x 2,260
Machine Weight (kg): 7,600
