MAIN MOTOR HP: 50 HP
VOLTAGE, FREQUENCY: 230/460 Volt 60HZ
PHASE: 3 Phase
AMP REQUIREMENT: 35/70 Amp
FEED SYSTEM: Feed Chain
FEED SPEED RANGE: 25-120 FPM
VARIABLE FEED SPEED: Manual Wheel Adjustment
ELEVATION HP: 1/4 HP
TOTAL MACHINE HP: 53.25 HP
APPROVED ELECTRICAL PARTS: CE Approved Components
DUAL VOLTAGE MOTORS: 230/460 Volt
CONTROL VOLTAGE: 110 Volt
ASSISTED START: Wye Delta
PASS-LINE: 33-1/2''
MIN. WORKING LENGTH: 17-3/4''
MIN. WORKING WIDTH: 27-1/8''
MIN. WORKING THICKNESS: 5/16''
MAX. WORKING THICKNESS: 4-15/16''
ARBOR RPM: 3570 RPM
BLADE SIZE: 12'' Tungsten Carbide Tipped
BLADE KERF: .140''
DUST PORT SIZE OUTLET: (2) 6'' Ports
ARBOR DIAMETER: 70 MM
HOLD DOWN STYLE: Pressure Shoe / Rollers
GUARDING: Full Cabinet Enclosure
OILER: Automatic Mechanical Oiler
FENCE TYPE: Adjustable
FRAME CONSTRUCTION: 5/16'' Steel Construction
WORKTABLE DIMENSIONS: 27-1/8'' x 64''
INFEED TABLE LENGTH: 13-3/4'' x 103''
DECIBEL RATING: 74 dB
NET WEIGHT: 4402 Lbs.
GROSS WEIGHT: 4402 Lbs.
