NEW NORTHTECH NT-2ST15XL

The NT 2ST-15XL is our 15HP fan with a primary cyclone filter. Cyclone style dust collectors use the speed of the air and the physics of centrifugal force to separate dust from the air. The natural cyclonic airflow allows clean air to pass through the center of the cyclone into the blower and through the secondary filter bags. A clean air mounted blower and steel cyclone design provides decades of dust separation without primary filter bags. The 2ST-15 cyclone and filter bag are supported by a steel frame structure that allows for the use of standard barrels for waste collection or connection to a rotary air lock.

Main Motor Hp.: 15 hp.
Voltage/ Freq.: 230/460 Volt 60Hz
Phase: 3 Phase
Amp Requirement: 18/36 Amps
Electronics: CE Approved Components
Dual Voltage: 230/460 Volt
Control Voltage: 220V Control Voltage
Assisted Start: Wye-Delta
Dust Port In: 12” Inlet
Dust Port Out: (3) 7” Bottom (2) 10” Top
Free Air CFM: 6200 CFM
Impeller: 25” Steel Impeller
Frame Const.: 1/8” Steel Construction
Upper Bags: 10” X 24” X 90.5”
Cyclone Diam.: 35” I.D.
No. of Barrels: 5 Barrels (Not Included)
No. of Dollies: 5 Barrel Dollies
Decible Rating: 89 dB
Net Weight: 1000 Lbs.
Gross Weight: 1165 Lbs.
Machine Dimensions: 80” x 61” x 138”
Packaging Dimensions: 51” x 48” x 73”
