NT-DC20 DUST COLLECTOR The NT DC20 is the smallest dust collector that Northtech offers. One of the few machines offered in single phase, this 2HP dust collector is a rugged portable model with a stamped steel housing, steel base and (4) casters in a compact design. While most often used as a single machine collector it can be fitted to collect from multiple small machines. The single bottom collection bag and oversized upper filter bag are a unique to Northtech dust collectors, providing a higher cloth to air ratio when compared to competitive models.
Main Motor Hp.: 2 hp.
Direct Drive: Direct Drive
Machine Hp.: 2 hp.
Voltage/ Freq.: 230/460 Volt 60Hz
Phase: 1 Phase
Amp Requirement: 7.35 Amps
Voltage/ Freq.: 230 Volt 60Hz
Electronics: CE Approved Components
Control Voltage: 220V Control Voltage
Dust Port Out: (1) 6”
Free Air CFM: 1300 CFM
Frame Const.: 1/16” Steel Construction
Upper Bags: 31” x 59”
Lower Bags: 31” x 34”
Decible Rating: 86 dB
Net Weight: 102 Lbs.
Gross Weight: 110 Lbs.
Machine Dimensions: 37” x 26” x 104”
Packaging Dimensions: 34” x 24” x 22”
