NEW GRIZZLY G0764Z

Safety note

Buying from non-Pro sellers
Non-Pro sellers can be individuals or smaller businesses. Equipt does not verify every seller or inspect every item. Confirm who you're dealing with, ask for recent photos or video, and only pay through secure, traceable methods.

This seller is not an Equipt Pro dealer. Equipt does not inspect items, handle payment or guarantee transactions. Verify the seller and equipment before sending funds.

725Listings|5Followers
Overview
Woodworking Panel Saws

This is the next level of Grizzly's industrial-sized sliding table saws, engineered to handle the largest sheet goods with a sliding table over ten feet long and capable of rips over 50" wide. Not only that—you can rip and crosscut the thickest material with a 4-1/8" maximum depth of cut at 90°. The independently controlled scoring blade eliminates tear-out and two flip stops on the crosscutting fence maximize production efficiency. The large overhead blade guard is fully adjustable and includes a 4" dust port, which supplements the 5" cabinet-mounted dust port. If you require a large sliding table saw, take a good look at this one! Made in an ISO 9001 factory FEATURES: Micro-adjustable rip fence Independently-powered scoring blade ensures tear-out free cutting Sliding table on steel ball guide system with heat-treated steel ways Alloy crosscut fence for miter cutting 45° right and left Miter fence has two flip stops for repetitive cutting Safety limit switch for blade cover Adjustable riving knife *Prewired for 220V. If you require 440V operation, Grizzly must convert your machine at the time of purchase. A $250 non-refundable fee will be added to your order. Please allow extra shipping time for the conversion. If you need more information, please contact technical service.

Specs

Main Motor: 10 HP, 220V/440V* (prewired for 220V), 3-phase, 29.2A/14.6A
Scoring motor: 1 HP
Rip capacity: 51-1/4"
Crosscut capacity: 124"
Blade tilt: 0 - 45°
Max. depth of cut @ 90°: 4-1/8"
Max. depth of cut @ 45°: 2-7/8"
Main table size with extensions: 35-1/4" x 59-1/8"
Sliding table size: 14" x 126"
Floor-to-table height: 34-1/2"
Main blade size: 14"
Main blade arbor: 1"
Main blade speed: 3000, 4000, 5000 RPM
Scoring blade size: 4-3/4"
Scoring blade arbor: 20mm
Scoring blade speed: 8000 RPM
Number of dust ports: 2
Dust port size: 4" & 5"
Footprint: 74-1/2" L x 35-1/2" W
Overall Size: 202" W x 133" D x 65" H
Approximate shipping weight: 1643 lbs.
