The NT TB25 is our 25HP direct drive transfer blower. The powerful direct drive design allows for a smaller footprint and rigid power delivery. The steel fabricated housing and frame provide long life while protecting the fan and motor. Northtech Transfer Blowers with controls and round pipe connection fitting make start up quick and easy.
Machine Hp.: 25 Hp.
Voltage/ Freq.: 230 Volt 60Hz
Phase: 3 Phase
Amp Requirement: 60.1 Amps
Electronics: CE Approved Components
Dual Voltage: 230/460 Volt
Control Voltage: 220V Control Voltage
Assisted Start: Wye Delta
Dust Port In: 18” Inlet
Impeller: 7” x 27” Impeller
Frame Const.: Steel Construction
Decible Rating: 80 dB
Net Weight: 1280 Lbs.
Gross Weight: 1465 Lbs.
Machine Dimensions: 72” x 48” x 71”
Packaging Dimensions: 76” x 49” x 64”
