NEW RITTER R823

The Ritter R823 is a robust, 23 spindle horizontal borer, designed to be used as a supplemental borer for CNC nested based router and point-to-point borer applications, producing clean and accurate drilling of wood components. The workpiece is held firmly against the table by a pneumatic clamps, and there is full adjustability of the index stops, bed height, and depth of cut. If you have need for a different machine configuration, check out the other horizontal borers in our line of machinery. Still not finding what you’re looking for? Give us a call, we are happy to discuss your specific application! 23-Horizontal Gear Driven Spindles 32mm Spindle Centers 10 Mm Bored Collets (12) Right Hand, (11) Left Hand 3,450 Spindle Rpm 3 H.P. Spindle Drive Motor, TEFC 0-2″ Adjustable Boring Depth 20″ X 42″ Precision Ground Table Back Fence Lip (2) End Boring Fences (1) 5-Ton Carriage Adjusting Jack (4) 2.00″ Bore Clamping Cylinder Wired 3-Phase 480 Volt, 60 Hz. (optional single-phase) Foot Pedal Actuated Boring Cycle No Tooling Included Designed And Manufactured In The USA Crate Dimensions: 54″ X 54″ X 55″ Weight: 1,485 Lbs
