MACHINE HP: 7.5 HP
REVERSIBLE MOTOR: Spindle Motor
VOLTAGE, FREQUENCY: 230/460 Volt 60Hz
PHASE: 3 Phase
AMP REQUIREMENT: 18 / 9 Amps
CONFIGURATION: Single Spindle
1ST SPINDLE: 1-1/4'' Spindle
SPINDLE LENGTH: 6''
SPINDLE DIAMETER: 1-1/4''
SPINDLE RPM: 3000, 4500, 6000, 9000 RPM
UNDER THE NUT CAPACITY: 5''
ELEVATION STYLE: Manual Wheel Adjustment
ELEVATION SYSTEM: Quill Housing Jack Screw
TOTAL MACHINE HP: 7.5 HP
APPROVED ELECTRICAL PARTS: CE Approved Parts
DUAL VOLTAGE MOTORS: 230/460 Volt
CONTROL VOLTAGE: 110 Volt
PASS-LINE: 33-1/2''
HORIZONTAL TRAVEL: 19-7/8'' Left 19-7/8'' Right
VERTICAL TRAVEL: 6'' on Spindle
DUST COLLECTION REQUIREMENT: 436 CFM @ Extraction Points
DUST PORT SIZE OUTLET: (1) 4'' Port
HOLD DOWN STYLE: Spring Tensioners
TOTAL CLAMPS: (1) Clamp
EMERGENCY STOP: (1) Front
FENCE TYPE: Adjustable
FENCE DIMENSIONS: (2) 5'' x 17''
MICRO FENCE: Micro Adjustable
SLIDING TABLE TRAVEL: 19-7/8'' Left and Right
BRAKE SYSTEM: Foot Pedal
FRAME CONSTRUCTION: Fabricated Steel
WORKTABLE DIMENSIONS: 41-3/16" x 31-3/8''
TABLE CONSTRUCTION MATERIAL: Machined Cast Iron
DECIBEL RATING: 70 dB
NET WEIGHT: 806 Lbs.
GROSS WEIGHT: 963 Lbs.
MACHINE DIMENSIONS: 42'' x 32'' x 42''
PACKAGING DIMENSIONS: 46'' x 37'' x 48''
