NEW NORTHTECH NT-CB1-21T

Northtech NT-CB1-21T (21) SPINDLE CONSTRUCTION BORING MACHINE

MACHINE HP: 2.5 HP
DIRECT DRIVE (MOTOR): Direct Drive
VOLTAGE, FREQUENCY: 230/460 Volt 60HZ
PHASE: 3 Phase
AMP REQUIREMENT: 16/8 Amps
SPINDLE ARRANGEMENT: 21 Spindle Fixed
SPINDLE DIAMETER: 10 MM
SPINDLE RPM: 3500 RPM
FEED SYSTEM: Pneumatic Cylinder
FEED SPEED RANGE: Adjustable Flow Control Valve
VARIABLE FEED SPEED: Flow Control Valve
ELEVATION STYLE: Manual Handle Adjustment
ELEVATION SYSTEM: Handle Jack Screw
TOTAL MACHINE HP: 2.5 HP
APPROVED ELECTRICAL PARTS: CE Approved Parts
DUAL VOLTAGE MOTORS: 230/460 Volt
CONTROL VOLTAGE: Line Voltage
HORIZONTAL TRAVEL: 2-3/16'' Travel
VERTICAL TRAVEL: 6 Position Turret
CYCLES/MINUTE: 12 Cycles a Minute Adjustable
HOLD DOWN STYLE: 4 Pneumatic Clamps
TOTAL CLAMPS: 4
FLR INCLUDED: Filter, Lubricator, Regulator
CFM AIR SUPPLY REQUIREMENT: 3/8'' Line @ 90 PSI
EMERGENCY STOP: (1) Front E-Stop
OPERATION STYLE: Foot Pedal
FENCE TYPE: Adjustable
FENCE DIMENSIONS: 1-5/8'' x 16'', 1-5/8'' x 118-1/4''
ADJUSTABLE STROKE: 6 Position Turret
TILT-ABLE: 0-90 Degrees
FRAME CONSTRUCTION: Fabricated Steel
WORKTABLE DIMENSIONS: 14-3/8'' x 35-1/2''
DECIBEL RATING: 78 dB
NET WEIGHT: 688 Lbs.
MACHINE DIMENSIONS: 33'' x 39'' x 47''
PACKAGING DIMENSIONS: 44'' x 36'' x 55''
