USED 2018 TORMACH 15L SLANT PRO

Horsepower: 3 hp
Swing Over Ways: 15 "
Swing Over Carriage: 6.2 "
Bore Diameter: 1.53 "
Voltage: 115/230 volts
Phase: Single-phase
Spindle Power: 3 hp // 2.24 kW
Spindle Speed:
Low: 180 to 2,500 RPM
High: 250 to 3,500 RPM
Spindle Taper: 5C (with removable insert)
Spindle Bore Diameter: 1.53 in. // 38.86 mm (with 5C insert removed)
Spindle Nose: D1-4 Camlock Mount
Max Feed Rate:
60 IPM // 1.52 m/min (X)
60 IPM // 1.52 m/min (Z)
Axis Drivers (X,Z): High-Performance Polyphase Stepper Motors with Leadshine Microstepping Drivers
X-Axis Travel: 10 in. // 254 mm
Z-Axis Travel: 12 in. // 305 mm
Recommended Chuck Size: 6 in. // 152 mm
