| Swing | 21" | 533.4 mm |
| Machining Length | 32.5" | 825.5 mm |
| Max. Turning Diameter | 15" | 381 mm |
| Distance Between Centers | 32.5" | 825.5 mm |
| X-Axis | 9.4" | 238.76 mm |
| Z-Axis | 32.5" | 825.5 mm |
| Rapid Traverse X-Axis | 945 ipm | |
| Rapid Traverse Z-Axis | 945 ipm | |
| Spindle Taper | A2-6 | A2-6 |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 3" | 76.2 mm |
| Spindle Bore | 3.5 in | |
| Spindle Nose | A2-6 | A2-6 |
| Power | 30 hp | 22.4 kW |
| Max RPM | 3,400 RPM | 3,400 RPM |
| Turret Stations | 12 | 12 |
| Tailstock | Yes | Yes |
| Dimensions | 171" x 90" x 98" | 171" x 90" x 98" |
| Weight | 10,900 Lbs | 10,900 Lbs |
HAAS CNC Control
Tailstock
Tool Presetter
Chip Conveyor
Includes all tooling on the turret and tool cabinet shown
