SERIAL ............................... 3349
MODEL ................................ RUR-1000
CAPACITY ............................. 11" X 40"
SWING OVER TABLE ..................... 11"
LONGITUDINAL TRAVEL .................. 41"
TABLE SWIVEL ......................... +/- 5 DEGREES
TABLE SPEEDS ......................... 7 TO 19 IPM
WHEEL SPEED .......................... 1700 TO 2100 RPM
SWING DOWN ID ........................ NO CARRIAGE
HYDRAULIC TABLE TRAVEL ............... 0 TO 100 FPM
WHEEL ................................ 14" X 1.5" X 5"
WORK HEAD SPEEDS ..................... (4) 95 TO 410 RPM
STEADY REST .......................... YES
TAPER TAIL STOCK ..................... #2 MT
ONE SHOT LUBE ........................ YES
COOLANT IN BASE ...................... YES
SPINDLE MOTOR ........................ 5 HORSEPOWER
Brand
ELGIN
Type
Grinders, Cylindrical, Universal
Stock No.
10741
