USED OMRON H7CX-AD

The Omron H7CX-AD is a compact multifunction preset counter designed for industrial counting and tachometer applications. This DIN 48×48mm counter features a bright 6-digit negative transmissive LCD display with backlight and provides versatile counting functions including 1-stage and 2-stage counter configurations, batch counting, and dual counter operation with addition/subtraction capabilities.
Specification
Value
Brand
Omron
Model/Part Number
H7CX-AD
Product Series
H7CX-A
Supply Voltage
12-24VDC
Number of Digits
6
Digit Height
10mm
Display Range
-99,999 to 999,999
Display Type
2-row 6-digit negative transmissive LCD with backlight
Output Type
SPDT Relay Contact
Contact Rating
250VAC/3A, 30VDC/3A
Input Type
No-voltage contact, NPN/PNP open collector (switchable)
Counting Speed
30Hz or 10Hz (switchable)
Memory Type
EEPROM (100,000 rewrites)
Operating Temperature
-10°C to +55°C
Storage Temperature
-25°C to +70°C
Dimensions
48mm × 48mm × 65mm (W×H×D)
Panel Cutout
44.8mm × 44.8mm
Terminal Type
Screw Terminals
Mounting
1/16 DIN (48×48mm) flush mounting
Protection Rating
IP66 (panel surface with optional waterproof packing)
Configuration
1-stage setting
Functions
Multifunction preset counter, tachometer, batch counter, dual counter
We warranty all items for 30 days from date of purchase.

SKU: AI1216
UPC: 679523686161
Condition: Used
Availability: In Stock
Weight: 1.00 LBS
Width: 7.00
(in)
Height: 6.00
(in)
Depth: 7.00
(in)
Shipping: Calculated at Checkout
GTIN: 679523686161
Mounting Style: Flush Mount
Current Rating: 3A
Output Type: SPDT relay contact
Manufacturer: Omron
Part Number: H7CX-AD
Series: H7CX-A
Shelf: F-10 Tub 1
Model: H7CX-AD
Coil Voltage: 12-24VDC
MPN: H7CX-AD
Type: Counter
